Nickel support mesh

Nickel Support Mesh for Electrolytic Cells

Nickel support mesh is a durable and corrosion-resistant material widely used in electrolytic cells. Its unique properties make it an ideal choice for supporting electrodes and facilitating efficient electrochemical processes. The open structure ensures optimal flow of electrolytes and gases, enhancing the overall performance and lifespan of the electrolytic cells.

Key Features:

1. High Corrosion Resistance:
   • Nickel support mesh is known for its exceptional resistance to corrosion, especially in harsh chemical environments. This ensures long-term durability and stability in electrolytic cells.
2. Excellent Electrical Conductivity:
   • The mesh offers superior electrical conductivity, which is crucial for efficient electrochemical processes. This conductivity ensures minimal energy loss and improved process efficiency.
3. Robust Mechanical Strength:
   • The structure of the nickel support mesh provides high mechanical strength and flexibility, making it capable of withstanding the rigorous conditions within electrolytic cells.
4. Good Permeability:
   • The open structure of the mesh ensures excellent permeability, allowing for optimal flow of electrolytes and gases. This permeability enhances the overall performance of the electrolytic process.

Features of Flexible Connection Membrane Electrode Gap Structure Elastic Support:

1. Protective Function:
   • The elastic support structure protects the membrane, extending its lifespan. By providing a cushioning effect, it prevents damage to the membrane during operation.
2. Enhanced Contact:
   • This structure increases the contact surface between electrodes and plates, ensuring more even current distribution. Improved contact leads to more efficient electrochemical reactions.
3. Bubble Cutting:
   • The elastic support structure helps cut bubbles, inhibiting the formation of large bubbles and effectively reducing gas resistance. This bubble management enhances process efficiency and stability.
4. Corrosion Resistance:
   • Woven from pure nickel wire, the elastic support structure effectively solves the problem of cavitation erosion. This ensures long-term performance in aggressive electrolytic environments.

Innovative Composite Electrodes:

Huirui Wire Mesh has developed an innovative solution by integrating low-aluminum electrodes with elastic supports to create elastic support composite electrodes. These electrodes offer several advanced features:

1. No Welding Needed:
   • This design avoids damage to the electrode frame coating caused by traditional welding processes. By eliminating welding, the integrity of the electrode frame is maintained.
2. Improved Contact:
   • The composite electrodes enhance the adhesion between electrodes and membranes, achieving true membrane electrode spacing. This precise spacing results in higher electrical efficiency and improved overall performance.
3. Economic Efficiency:
   • The innovative design allows for a reduction in the number of cells by approximately 20%, offering significant cost savings. Fewer cells mean reduced material and maintenance costs, making the process more economical.
