Stainless Steel Wire Mesh for Filter & Support Applications
Stainless Steel Wire Mesh is a critical material used as support layer and filtration media inside hydraulic filter elements, air filters, fuel filters and industrial filtration systems. It is manufactured from high-quality stainless steel wire with precise plain weave, offering excellent corrosion resistance, stable structure and uniform openings.
We supply a complete range of stainless steel wire mesh suitable for excavator filters, heavy-duty filters and OEM/aftermarket filter element production.
Key Features
- Excellent corrosion resistance (SS304 / SS316 / SS316L)
- Uniform mesh openings and stable structure
- High strength and good durability
- Suitable for filter support and precision filtration
- Customizable width and length
- Free samples available
Available Specifications
| Mesh Count | Typical Wire Diameter | Material |
|---|---|---|
| 40×36 Mesh | 0.20 – 0.25 mm | SS304 / SS316 / SS316L |
| 40 Mesh | 0.20 – 0.25 mm | SS304 / SS316 / SS316L |
| 80 Mesh | 0.12 – 0.16 mm | SS304 / SS316 / SS316L |
| 100 Mesh | 0.10 – 0.12 mm | SS304 / SS316 / SS316L |
| 150 Mesh | 0.06 – 0.07 mm | SS304 / SS316 / SS316L |
| 200 Mesh | 0.05 – 0.06 mm | SS304 / SS316 / SS316L |
| 300 Mesh | 0.035 – 0.04 mm | SS304 / SS316 / SS316L |
| 400 Mesh | 0.025 – 0.03 mm | SS304 / SS316 / SS316L |
Other Parameters
- Weave Type: Plain Weave
- Width: Customizable (common range 0.5–1.5 m, other sizes available)
- Length: Customizable according to customer requirements
- Supply Form: Rolls or cut-to-length sheets
Applications
- Hydraulic filter elements for excavators, loaders, bulldozers (CAT, Komatsu, Hitachi, Volvo, etc.)
- Air filter and fuel filter support layers
- OEM and aftermarket heavy-duty filters
- Industrial filtration systems
Why Choose Huirui?
- Over 15 years specialized experience in wire mesh manufacturing
- Long-term continuous supply to Japanese brand (Yamashin) filter production in Philippines & Vietnam
- Strict quality control and consistent performance
- Flexible customization for mesh count, wire diameter, material, width and length
- Free samples available for quality evaluation
- Fast response and professional export service
Contact us for free samples, detailed specifications and competitive quotation. We can produce according to your required mesh count, wire diameter, width and length.
